Teflon Coated Glass Fabric Tape 6 Mil - TapeJungle.com
Zoom the image with the mouse
Teflon Coated Glass Fabric Tape 6 Mil - TapeJungle.com

PTFE Coated Glass Fabric Tape 6 Mil (78106)

PTFE Coated Glass Fabric Tape

36 Yards, Brown, PTFE impregnated fiberglass cloth, consisting of warp and fill yarns, and coated with a high temperature silicone adhesive. Excellent electrical, mechanical and chemical properties. Used as a primary insulation in a variety of electrical equipment and heat sealing bars, chute liners, gaskets, bearing surfaces, tabletop covers, guide rails and roll covers. Low friction surface; abrasion resistant. Product comes standard with liner. Self-wound is optional at no additional cost.

PTFE coated glass fabrics (without adhesive) are also available.

Roll size of “NA”: 37-1/2” wide x 36 yd or 18 yd lengths. Call for pricing. 1/2” AND 3/4” WIDE ROLLS MUST BE SELF WOUND.

Operating temperature range: -100°F to +500°F (-73°C to +260°C). 3” plastic core.

Physical Properties:

Backing   5.4 mil/0.0054”
Total thickness   0.0084”
Breaking strength, Warp/fill (lb/in)   150/140
Peel strength (oz/in)   40
Elongation, Warp/fill   3.0%/4.0%
Electrical strength (total volts)   6500

Alternative to 3M #5453; DeWal #134-6; St. Gobain #SG25-06; Greenbelt #100-6S; W.F. Lake #L-40S-6; Taconic #6085-06; Chemfab #350-6S; Lanmar #635-6; AFC #25006S

Note: The physical properties listed above are typical test results obtained from a series of laboratory tests and should not be used for the purpose of writing specifications. Before using this product, user shall determine the suitability of the product for his/her use; and user assumes all risks and liabilities in connection therewith. All test procedures used are in accordance with ASTM and PSTC methods.
